All productsShowing 379–396 of 459 results
Monoblock Directional Valve Q45: 11.8 GPM Flow, Solenoid & Manual 5 Spool Control
In stock
| Weight | 19.00 kg |
|---|---|
| Dimensions | 30 × 35 × 17 cm |
| Control Method |
Solenoid And Manual |
| Spool |
5 Spool |
| Rated Flow |
45 L/min (11.8 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Inlet Port |
G1/2 |
| Outlet Port |
G1/2 |
| Port Size |
G1/2 |
| Section |
1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type |
Monoblock valve |
| Product Model |
Q45 Solenoid And Manual |
Monoblock Directional Valve VMS140 – 39.6 GPM, Pneumatic 1 Spool for Hydraulic Applications
In stock
| Weight | 6.00 kg |
|---|---|
| Dimensions | 25 × 17 × 17 cm |
| Control Method |
Pneumatic |
| Spool |
1 Spool |
| Rated Flow |
150 L/min (39.6 US gpm) |
| Max Pressure |
230 bar (3300 psi) |
| Inlet Port |
G1 |
| Outlet Port |
G3/4 |
| Port Size |
G1 |
| Section |
1 Section |
| Structure Type |
Monoblock valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-20°C to +80°C (-4°F to +176°F) |
| Pneumatic Control Pressure |
7-12 bar |
| Product Model |
VMS140 Pneumatic |
Monoblock Electro-hydraulic Directional Control Valve – 5 Spool P80, 21.2 GPM
In stock
| Weight | 23.00 kg |
|---|---|
| Dimensions | 52 × 42 × 20 cm |
| Control Method |
electro-hydraulic |
| Section |
5 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
250 bar (3600 psi) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
5 Spool |
| Inlet Port |
G1/2 |
| Outlet Port |
G3/4 |
| Port Size |
G1/2 |
| Product Model |
P80 Electro-hydraulic |
Monoblock Electro-hydraulic Directional Valve – 1 Spool, 11.8 GPM, SD5 Series
In stock
| Weight | 6.00 kg |
|---|---|
| Dimensions | 30 × 25 × 17 cm |
| Control Method |
Electro-hydraulic |
| Spool |
1 Spool |
| Rated Flow |
45 L/min (11.8 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Inlet Port |
G1/2 |
| Outlet Port |
G1/2 |
| Port Size |
G1/2 |
| Section |
1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type |
Monoblock valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Product Model |
SD5 Electro-hydraulic |
Monoblock Solenoid Directional Valve 10.5 GPM, 4 Spool (P40-S Model)
In stock
| Weight | 12.70 kg |
|---|---|
| Dimensions | 30 × 30 × 16 cm |
| Control Method |
solenoid |
| Section |
4 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
250 bar (3600 psi) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
4 Spool |
| Inlet Port |
G1/2 |
| Outlet Port |
G1/2 |
| Port Size |
G3/8 |
| Product Model |
P40-S Solenoid |
MP80 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
80 L/min (21 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
MPC70 Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
70 L/min (12 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
OEM & Wholesale Monoblock Directional Valve (VMS140) – 39.6 GPM Pneumatic 1 Spool – Hydraulic Manufacturing
In stock
| Weight | 6.00 kg |
|---|---|
| Dimensions | 25 × 17 × 17 cm |
| Control Method |
Pneumatic |
| Spool |
1 Spool |
| Rated Flow |
150 L/min (39.6 US gpm) |
| Max Pressure |
230 bar (3300 psi) |
| Inlet Port |
G1 |
| Outlet Port |
G3/4 |
| Port Size |
G1 |
| Section |
1 Section |
| Structure Type |
Monoblock valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-20°C to +80°C (-4°F to +176°F) |
| Pneumatic Control Pressure |
7-12 bar |
| Product Model |
VMS140 Pneumatic |
P120 Directional Control Valve
In stock
| Model No. |
P120 Series Hydraulic Valve |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
120 L/min (31.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P120 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
120 L/min (31.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Cable Directional Control Valve
In stock
| Control Method |
cable |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Directional Control Valve
In stock
| Model No. |
P40 Series Hydraulic Valve |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Electro-hydraulic Directional Control Valve
In stock
| Control Method |
electro-hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Electro-pneumatic Directional Control Valve
In stock
| Control Method |
electro-pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Hydraulic Directional Control Valve
In stock
| Control Method |
hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Joystick Directional Control Valve
In stock
| Control Method |
joystick |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
P40 Pneumatic Directional Control Valve
In stock
| Control Method |
pneumatic |
|---|---|
| Model No. |
P40 Series Hydraulic Valve |
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
40 L/min (10.5 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
Maximum 250 bar at P Port |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Spool Stroke |
±6mm |
| Valve Structure |
Monoblock Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-7 sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
