Global Supplier of Sectional Directional Valves: SDS180 Series (42.2 GPM, Manual/Hydraulic) – Partner Opportunities
In stock
| Weight | 35.00 kg |
|---|---|
| Dimensions | 40 × 30 × 15 cm |
| Control Method |
Hydraulic and Manual |
| Section |
3 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
160 L/min (42.2 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Inlet Port |
G3/4 |
| Outlet Port |
G1 |
| Port Size |
G3/4 |
| Product Model |
SDS180 Hydraulic and Manual |
Global Supply & Partnership for DCV200-FB: 52 GPM Electro-Hydraulic 1 Spool Sectional Directional Valves
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 45 × 25 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
1 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
200 L/min (52 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Inlet Port |
G1 |
| Outlet Port |
G1 |
| Port Size |
G1 |
| Product Model |
DCV200-FB Electro-hydraulic |
Global Supply: 5 Spool Electric Proportional Sectional Directional Valves 10.5 GPM DCV56
In stock
| Weight | 27.20 kg |
|---|---|
| Dimensions | 37 × 31 × 28.5 cm |
| Control Method |
Electric proportional |
| Spool |
5 Spool |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
305 bar (4400 psi) |
| Inlet Port |
G1/2 |
| Outlet Port |
G1/2 |
| Port Size |
G3/8 |
| Section |
1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section, 8 Section, 9 Section, 10 Section, 11 Section, 12 Section |
| Structure Type |
Sectional valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Product Model |
DCV56 Electric proportional |
High Flow 39.6 GPM Hydraulic Sectional Valve: Dual Manual & Electro-hydraulic Control Options
In stock
| Dimensions | 48 × 64 × 19 cm |
|---|---|
| Control Method |
Manual and Electro-hydraulic |
| Spool |
10 Spool |
| Rated Flow |
150 L/min (39.6 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Inlet Port |
3/4 NPT |
| Outlet Port |
1 NPT |
| Port Size |
3/4 NPT |
| Section |
1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section, 8 Section, 9 Section, 10 Section, 11 Section, 12 Section |
| Structure Type |
Sectional valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Product Model |
DCV150-10-NPT Manual and Electro-hydraulic |
High Flow Sectional Directional Control Valve, Manual 4-Spool, 42.2 GPM, with Electric Unloading Function
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 45 × 25 × 18 cm |
| Control Method |
manual |
| Section |
4 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
160 L/min (42.2 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Inlet Port |
G3/4 |
| Outlet Port |
G1 |
| Port Size |
G3/4 |
| Product Model |
HSDLS180-Electric unloading valve Manual |
HSDLS180 Series Manual 4-Spool Sectional Directional Valve, 42.2 GPM, Integrated Electric Unloading
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 45 × 25 × 18 cm |
| Control Method |
manual |
| Section |
4 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
160 L/min (42.2 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Inlet Port |
G3/4 |
| Outlet Port |
G1 |
| Port Size |
G3/4 |
| Product Model |
HSDLS180-Electric unloading valve Manual |
HSDS15 Hydraulic Valve: 15.8 GPM 3-Spool Manual Directional Valve – Manufacturer & Distributor
In stock
| Weight | 11.50 kg |
|---|---|
| Dimensions | 23.5 × 22 × 11 cm |
| Control Method |
manual |
| Section |
3 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
60 L/min (15.8 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Spool |
3 Spool |
| Product Model |
HSDS15 Manual |
HSDS15 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
60 L/min (15.8 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
315 bar (31.5 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSDS25 Hydraulic Directional Control Valve
In stock
| Control Method |
hydraulic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
240 L/min (63 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSDS25 Manual Directional Control Valve
In stock
| Control Method |
manual |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
240 L/min (63 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
250 bar (25 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSDSL Load Sensitive Proportional Control Valve
In stock
| Control Method |
electric proportional, electric proportional & manual, hydraulic, hydraulic & manual |
|---|---|
| Valve Structure |
Sectional Valve |
| Nominal Flow |
140 L/min (37 gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Valve Sections |
1-12 Sections |
| Suitable For Hydraulic Systems |
Quantitative pump systems |
| Auxiliary Parts |
Pressure limiting safety valve, Oil supply safety valve, One-way(check) valve,Balance valve |
HSDVG32 Load Sensitive Proportional Control Valve
In stock
| Control Method |
electric proportional, electric proportional & manual, hydraulic, hydraulic & manual |
|---|---|
| Valve Structure |
Sectional Valve |
| Nominal Flow |
140 L/min (37 gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Valve Sections |
1-12 Sections |
| Suitable For Hydraulic Systems |
Quantitative pump systems |
| Auxiliary Parts |
Pressure limiting safety valve, Oil supply safety valve, One-way(check) valve,Balance valve |
HSSD Directional Control Valve
In stock
| Flow |
45~380 L/min |
|---|---|
| Operating Pressure |
250-350 bar (25-35 MPa) |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Viscosity Range |
12-400 mm²/s |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
monoblock, sectional |
| Valve Sections |
1-12 Sections |
| Presure Medium |
Mineral oil based hydraulic oil |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Spool Stroke |
±6mm |
| Valve Surface |
Phosphating treating |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD6 Directional Control Valve
In stock
| Control Method |
cable, electro-hydraulic, electro-pneumatic, joystick, manual, pneumatic |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
45 L/min (12 gpm) |
| Operating Range |
15-75 mm²/s (15-75 CST) |
| Operating Pressure |
315 bar (31.5 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +60°C (-40°F to +140°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-10 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
HSSD8 Forest Crane Valve
In stock
| Control Method |
solenoid |
|---|---|
| Presure Medium |
Mineral oil based hydraulic oil |
| Nominal Flow |
80 L/min (21 gpm) |
| Viscosity Range |
12 CST-400 CST |
| Operating Pressure |
315 bar (31.5 MPa) |
| Internal Leakage |
15 cc/min at 160 bar, 50℃ |
| Ambient Temp |
-40°C to +80°C (-40°F to +176°F) |
| Valve Structure |
Sectional Valve |
| Valve Surface |
Phosphating treating |
| Valve Sections |
1-12 Sections |
| Rustproof Level |
Neutral salt spray test, 48hours |
Our Products and Services
Here's what we can do
Our main products include Directional Control Valves, Gear Pumps, Steering Equipment, and Power Units, with over 500 models that are widely used in various industries such as construction, sanitation, drilling, and mining. In addition to our standard product offerings, we also support OEM/ODM services, allowing us to customize hydraulic products according to our customers' specific needs and requirements. Our professional R&D team and advanced production technology ensure the quality and timely delivery of our products, while our comprehensive pre-sales and after-sales services help our customers improve their product competitiveness.
