All productsShowing 1–18 of 53 results
10.5 GPM 2-Spool Electro-Hydraulic Directional Valve (P40) – Manufacturer, Distributor & Wholesale Opportunities
In stock
| Weight | 9.30 kg |
|---|---|
| Dimensions | 31 × 18 × 17 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
250 bar (25 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
P40 Electro-hydraulic |
10.5 GPM 4-Spool Electro-Hydraulic Directional Valves: Manufacturing, OEM, & Distribution
In stock
| Weight | 16.50 kg |
|---|---|
| Dimensions | 31 × 24 × 17 cm |
| Control Method |
electro-hydraulic |
| Section |
4 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
40 L/min (10.5 US gpm) |
| Max Pressure |
250 bar (25 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
4 Spool |
| Product Model |
P40 Electro-hydraulic |
21.2 GPM Electro-hydraulic 5 Spool Monoblock Directional Valve (P80 Model)
In stock
| Weight | 23.00 kg |
|---|---|
| Dimensions | 52 × 42 × 20 cm |
| Control Method |
electro-hydraulic |
| Section |
5 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
250 bar (3600 psi) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
5 Spool |
| Inlet Port |
G1/2 |
| Outlet Port |
G3/4 |
| Port Size |
G1/2 |
| Product Model |
P80 Electro-hydraulic |
21.2 GPM Electro-hydraulic Directional Valve (P80) – Global Manufacturer & Supplier Seeking Distributors
In stock
| Weight | 15 kg |
|---|---|
| Dimensions | 40 × 45 × 25 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
P80 Electro-hydraulic |
23.8 GPM Electro-Hydraulic 4 Spool Directional Valve (SD8-PG2) – Global Supplier, Wholesale & Distribution
In stock
| Weight | 28.00 kg |
|---|---|
| Dimensions | 40 × 35 × 20 cm |
| Control Method |
electro-hydraulic |
| Section |
4 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
90 L/min (23.8 gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
4 Spool |
| Product Model |
SD8-PG2 Electro-hydraulic |
| Inlet Port |
G1/2 |
| Outlet Port |
G3/4 |
| Port Size |
G1/2 |
3 Spool Electro-hydraulic Sectional Directional Valve – 26.5 GPM Performance
In stock
| Weight | 29.00 kg |
|---|---|
| Dimensions | 37 × 30 × 16 cm |
| Control Method |
electro-hydraulic |
| Section |
3 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
100 L/min (26.4 gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Spool |
3 Spool |
| Inlet Port |
G3/4 |
| Outlet Port |
G3/4 |
| Port Size |
G3/4 |
| Product Model |
DCV100-OT-J-OT Electro-hydraulic |
42.2 GPM Monoblock Directional Valve (Electric 2 Spool SD18) – Seeking Distributors, Agents & Trade Partners
In stock
| Weight | 22.50 kg |
|---|---|
| Dimensions | 21 × 47 × 32 cm |
| Control Method |
Electric |
| Section |
2 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
160 L/min (42.2 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Inlet Port |
G1 |
| Outlet Port |
G1 |
| Port Size |
G1 |
| Product Model |
SD18 Electric |
52 GPM 2 Spool Electro-hydraulic Directional Control Valve (DCV200) – Global Supplier & Distributor
In stock
| Weight | 33.00 kg |
|---|---|
| Dimensions | 48 × 30 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
200 L/min (52 US gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
DCV200 Electro-hydraulic |
Advanced 18.5 GPM Electro-hydraulic 4 Spool Valves: Global Manufacturing & Partnership Opportunities
In stock
| Weight | 17.90 kg |
|---|---|
| Dimensions | 29 × 30 × 20 cm |
| Control Method |
electro-hydraulic |
| Section |
4 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
70 L/min (18.5 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Inlet Port |
G3/4 |
| Outlet Port |
G3/4 |
| Port Size |
G1/2 |
| Product Model |
SD11-PG2 Electro-hydraulic |
BXHS Electro-hydraulic Directional Control Valve (26.5 GPM, 2 Spool) – DCV100 Wholesale & Distribution Available
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 41 × 30 × 16 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
100 L/min (26.4 gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
DCV100 Electro-hydraulic |
BXHS Electro-Hydraulic Directional Valves (21.2 GPM, 3 Spool) – Manufacturer & Distributor
In stock
| Weight | 18.00 kg |
|---|---|
| Dimensions | 35 × 38 × 21 cm |
| Control Method |
electro-hydraulic |
| Section |
3 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
80 L/min (21.2 US gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
3 Spool |
| Product Model |
P80 Electro-hydraulic |
China Sectional Directional Valve DCV200-FB: 52 GPM Electro-Hydraulic 1-Spool
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 45 × 25 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
1 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
200 L/min (52 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Inlet Port |
G1 |
| Outlet Port |
G1 |
| Port Size |
G1 |
| Product Model |
DCV200-FB Electro-hydraulic |
Customizable 52 GPM Electro-Hydraulic 1 Spool Sectional Directional Valve (DCV200-FB) | Private Label & Manufacturing Services
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 45 × 25 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
1 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
200 L/min (52 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Inlet Port |
G1 |
| Outlet Port |
G1 |
| Port Size |
G1 |
| Product Model |
DCV200-FB Electro-hydraulic |
Customizable Monoblock Directional Valves | 11.8 GPM Electro-hydraulic 2 Spool SD5 – OEM, ODM & Private Labeling Services
In stock
| Weight | 9.00 kg |
|---|---|
| Dimensions | 35 × 27 × 17 cm |
| Control Method |
Electro-hydraulic |
| Spool |
2 Spool |
| Rated Flow |
45 L/min (11.8 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Inlet Port |
G1/2 |
| Outlet Port |
G1/2 |
| Port Size |
G1/2 |
| Section |
1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type |
Monoblock valve |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Product Model |
SD5 Electro-hydraulic |
DCV100-OT-J-OT Sectional Electro-hydraulic Valve – 26.5 GPM Flow Rate
In stock
| Weight | 29.00 kg |
|---|---|
| Dimensions | 37 × 30 × 16 cm |
| Control Method |
electro-hydraulic |
| Section |
3 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
100 L/min (26.4 gpm) |
| Max Pressure |
315 bar (31.5 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Spool |
3 Spool |
| Inlet Port |
G3/4 |
| Outlet Port |
G3/4 |
| Port Size |
G3/4 |
| Product Model |
DCV100-OT-J-OT Electro-hydraulic |
Electric 2 Spool Monoblock Hydraulic Valve SD18 – Custom Manufacturing & Global Wholesale Supply
In stock
| Weight | 22.50 kg |
|---|---|
| Dimensions | 21 × 47 × 32 cm |
| Control Method |
Electric |
| Section |
2 Section |
| Structure Type |
Monoblock valve |
| Rated Flow |
160 L/min (42.2 US gpm) |
| Max Pressure |
315 bar (4600 psi) |
| Operating Viscosity Range |
12 – 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Inlet Port |
G1 |
| Outlet Port |
G1 |
| Port Size |
G1 |
| Product Model |
SD18 Electric |
Electro-hydraulic DCV60 Valves: 15.8 GPM, 2 Spool Sectional Directional Valves – Global Supplier
In stock
| Weight | 15.60 kg |
|---|---|
| Dimensions | 23 × 15 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
2 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
60 L/min (15.8 US gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
2 Spool |
| Product Model |
DCV60 Electro-hydraulic |
Electro-hydraulic Directional Control Valve (DCV200): 52 GPM, 1 Spool – Global Supply & Distribution
In stock
| Weight | 24.00 kg |
|---|---|
| Dimensions | 48 × 30 × 18 cm |
| Control Method |
electro-hydraulic |
| Section |
1 Section |
| Structure Type |
Sectional valve |
| Rated Flow |
200 L/min (52 US gpm) |
| Max Pressure |
350 bar (35 MPa) |
| Operating Viscosity Range |
15 – 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range |
-40°C to +80°C (-40°F to +176°F) |
| Spool |
1 Spool |
| Product Model |
DCV200 Electro-hydraulic |
